Aignep Usa 80621-06 - Safety Exhaust Coupler,3/8",Brass
Aignep Usa 80621-06 - Safety Exhaust Coupler,3/8",Brass
Couldn't load pickup availability
Ships factory-new in original packaging.
Not sure if a compatible flange, seal kit, or accessory exists for this item? Ask our team — we're happy to help you find the right part.
TIPS Contract Vendor
Officially awarded purchasing cooperative vendor.
Why Buy From Us
Every quote personally reviewed. Direct sourcing from top manufacturers.
The AIGNEP USA - 80621-06 is a designed for pneumatic service; provides push/pull actuation for connection/disconnection without required hand tools. It features a push/pull mechanism with vented locking design and includes an integrated poppet valve to control air flow. The fitting is constructed from brass with zinc black anodized finish; uses a nitrile seal. It is rated for a maximum flow rate of 595 L/min and a maximum working pressure of 220 psi at 70°F. The coupling is sized for 1/4 inch connections, with a 3/8 inch hose fitting size and 3/8"-18 thread size, made to Industrial interchange specifications.
Key Features:
- - Application: Pneumatic service
- - Material: Brass with zinc black anodized finish
- - Seal material: Nitrile
- - Coupling size: 1/4 in
- - Hose fitting size: 3/8 in, male gender
- - Thread size: 3/8"-18
- - Coupling component: Socket
- - Coupling locking: Safety vent mechanism
- - Valve: Integrated poppet type valve
- - Max. flow rate: 595 lpm
- - Max. working pressure: 220 psi @ 70°F
- - Overall length: 2 3/16 in
- - Max. outside diameter: 1 3/16 in
- - Temperature range: 0°F to 180°F
- - Interchange type: Industrial
