Asco 8215C063CSA - Solenoid Valve, 2-Way, 2-Position, Normally Open, 1-1/4 in Pipe Size, 120 V AC, High Flow, Aluminum

The ASCO 8215C063CSA solenoid valve is a direct-acting, 2-way, 2-position valve with a normally open starting configuration designed for controlling the flow of air and vacuum. It features an aluminum body and a valve design: 2-Way/2-Position; direct acting. This valve operates within an ambient temperature range of 14°F to 140°F and can handle fluid temperatures up to 125°F. Environmental Rating: Hazardous, Indoor, Outdoor. It includes the coil as well as sealing components. The valve is operated at 120V AC, consuming 15.4 W of power at 60 Hz frequency.

Key Features:

• - Valve Design: 2-Way/2-Position, normally open configuration
• - Valve Type: High Flow, direct acting operation
• - Body Material: Aluminum
• - Media: Air, Fuel Gas
• - Operating Pressure Differential: 0 psi minimum, 25 psi maximum for air, fuel gas, and water
• - Orifice Diameter: 1-5/8 in
• - Nominal Pipe Size: 1-1/4 in with NPTF inlet and outlet connections
• - Coil Enclosure: Without Junction Box, watertight with Class F insulation
• - Electrical Connections: 1/2 in conduit with 18 in leads
• - Voltage: 120V AC at 60 Hz
• - Wattage: 15.4 W
• - Response Time: 120 milliseconds
• - Environmental Rating: Hazardous, Indoor, Outdoor
• - Seal Material: NBR
• - IP Rating: IP65
• - Overall Dimensions: Height 6-11/16 in, Length 5 in, Width 5-3/8 in
• - Includes coil and seal components
• - Standards: CSA, UL
• - NEMA Enclosure Rating: 1
• - Center Line Pipe Center Size: 3-5/8 in
