Bell & Gossett 115114 BB-3X Suction Diffuser Plus (2 Inch NPT x 2 Inch NPT, Cast Iron, 175 PSI)
Bell & Gossett 115114 BB-3X Suction Diffuser Plus (2 Inch NPT x 2 Inch NPT, Cast Iron, 175 PSI)
National Boiler Supply is a premier, authorized procurement distributor for high-efficiency commercial equipment. Every order ships factory-direct, completely insured, and backed by full manufacturer engineering warranties and technical field support.
| Performance Parameter | Engineering Baseline Value |
|---|---|
| Manufacturer Part Number (MPN) | 115114 |
| Model Designation | BB-3X Suction Diffuser Plus |
| System Inlet Size / Connection | 2" NPT (Female Threaded) |
| Pump Outlet Size / Connection | 2" NPT (Female Threaded) |
| Maximum Working Pressure | 175 PSI (12 bar) |
| Maximum Operating Temperature | 250°F (121°C) |
| Body / Cover Plate Material | Cast Iron (EPDM O-Ring Seal) |
| Start-Up Strainer Screen | 16-Mesh Bronze (Disposable) |
Couldn't load pickup availability
TIPS Contract Vendor
We are an officially awarded purchasing cooperative vendor.
📋 Procurement & Logistics Notice
Fulfillment parameters vary based on active supply chain distributions and contract schedules:
- Standard inventory configurations typically dispatch within 24 to 48 hours.
- High-capacity commercial units or specialty phase requirements may face factory production lead times.
Need precise lead times, formal submittals, or shipping coordination for contract fulfillment? Please Request a Commercial Quote or contact our procurement support line.
Corporate Procurement & PO Processing
Formal Purchase Orders (POs) and tax-exempt ordering are accepted for commercial contractors and institutional facilities.
Apply for Trade Account & Terms →Bell & Gossett 115114 (Model BB-3X) Suction Diffuser Plus
Engineered to optimize flow conditioning and protect centrifugal pumps in hydronic heating and cooling systems, the Bell & Gossett 115114 (Model BB-3X) Suction Diffuser Plus is an angle-pattern flow-straightening fitting. Featuring 2" NPT female threaded system and pump connections, this unit mounts directly to the pump suction inlet to eliminate long straight pipe runs and costly reducing elbows.
The Suction Diffuser Plus incorporates B&G's patented Flow Cone design, which eliminates fluid recirculation zones, directs media into the pump inlet, and ensures a uniform velocity profile to reduce stress on the impeller and shaft. It is factory-equipped with a heavy-duty orifice cylinder for continuous debris protection and a 16-mesh bronze fine start-up strainer to clean foreign particles during initial system commissioning.
Key Engineering Features:
- Patented Flow Cone Technology: Directs fluid smoothly into the pump suction, eliminating turbulence and retaining maximum pump operating efficiency.
- Space-Saving Angle Pattern: Combines an elbow, flow straightener, reducer, and strainer into a single compact fitting to conserve mechanical room footprint.
- Dual Strainer Protection: Features a durable orifice cylinder for permanent pump protection plus a disposable 16-mesh bronze start-up strainer for system flushing.
- Easy Internal Access: Removable end cover with reusable EPDM O-ring seal permits quick inspection, blow-down flushing, and start-up strainer removal.
⚠️ Application Profile: Ideal for commercial HVAC, closed-loop hydronic heating, chilled water systems, and general industrial pumping applications operating up to 175 PSI and 250°F.
