Bell & Gossett Series 60 1.25-Inch In-Line Pump
Bell & Gossett Series 60 1.25-Inch In-Line Pump
Couldn't load pickup availability
TIPS Contract Vendor
We are an officially awarded purchasing cooperative vendor.
📋 Procurement & Shipping Notice
- LTL Freight Dispatch: Heavy commercial units ship directly via insured LTL carrier with delivery coordination included.
- Project Timelines & Submittals: Need guaranteed delivery dates, formal submittals, or tax-exempt processing?
👉 Request a Commercial Quote or contact our procurement team for direct freight scheduling.
Corporate Procurement & PO Processing
Formal Purchase Orders (POs) and tax-exempt ordering are accepted for commercial contractors and institutional facilities.
Apply for Trade Account & Terms →Technical Specifications Matrix:
| Manufacturer Part Number (MPN) | 1EF016LF (Standard 1/4 HP Single-Phase Baseline) |
| Pump Size / Connections | 1-1/4" x 1-1/4" x 5-1/4" (Flanged Connection) |
| Motor Speed / RPM | 1750 RPM |
| Maximum Working Pressure | 175 psi (12 bar) |
| Standard Fluid Temperature Limit | -20°F to 225°F (-29°C to 107°C) |
| Pump Construction Style | Bronze-Fitted Cast Iron Volute |
| Mechanical Seal Assembly | Internally Self-Flushing EPR/Carbon/Silicon-Carbide Type |
| Lubrication Framework | Permanently Lubricated / Maintenance-Free Bearings |
| Product Shipping Weight | 51.00 lbs |
The Bell & Gossett Series 60 / e-60 is a three-piece, close-coupled in-line centrifugal pump built to deliver quiet, high-efficiency performance for commercial and light commercial hydronic heating, cooling, and potable water circulation loops. Engineered to maximize fluid movement while taking up minimal mechanical room floor space, its compact, inline footprint integrates directly into your existing pipe lines without demanding complex secondary supports or specialized base frames.
Equipped with a permanently lubricated, maintenance-free bearing assembly and motor network, this series completely eliminates the need for periodic manual regreasing. A standard, unitized internal self-flushing mechanical seal continuously bathes the contact surfaces to purge circulating system grit and particles away from the shaft, ensuring structural reliability, preventing shaft scoring, and extending the service lifespan of the plant's mechanical equipment.
Product Documents
