• Eaton XTCE007B01C - IEC Magnetic Contactor, 1 NC, 480 V AC, 3 P, Non-Reversing, Screw
1 1

Eaton XTCE007B01C - IEC Magnetic Contactor, 1 NC, 480 V AC, 3 P, Non-Reversing, Screw

Eaton XTCE007B01C - IEC Magnetic Contactor, 1 NC, 480 V AC, 3 P, Non-Reversing, Screw

Brand: Eaton SKU: XTCE007B01C
$114.44 USD
$114.44 USD
Sale Out of Stock - Call to Order
In Stock — Ships TODAY if ordered before 2:00 PM EST
OEM manufacturer warranty Genuine factory-sourced

Ships factory-new in original packaging.

📋 Request a Commercial Quote / PO

Not sure if a compatible flange, seal kit, or accessory exists for this item? Ask our team — we're happy to help you find the right part.

Official TIPS Contract Awarded Vendor Badge

TIPS Contract Vendor

Officially awarded purchasing cooperative vendor.

✓

Why Buy From Us

Every quote personally reviewed. Direct sourcing from top manufacturers.

View full details

The Eaton XT IEC contactor is a 3-pole, non-reversing IEC magnetic contactor with a 480V AC coil. It is rated for a maximum continuous current of 7A inductive and 22A resistive under specified conditions. The unit uses screw terminals, is frame size B in the XT series, and supports DIN Rail or panel mounting. It has been tested and certified by UL and CSA according to applicable standards, is suitable for use within voltage ratings up to 690V AC as specified in product documentation, and is designed to operate within the frequency range of 50/60 Hz. The enclosure is provided without an enclosure; suitable for installation in environments compliant with IP20 standards.

- Coil voltage: 480V AC

  • - Action/Reversing: Non-Reversing; Reversing: No
  • - Poles and contact configuration: 3 poles; Auxiliary contacts: 1 NC
  • - Auxiliary contact form: 1NC
  • - Maximum voltage rating: 690V AC
  • - Certifications: UL Listed; CSA Certified
  • - Mounting: DIN Rail, Panel
  • - Electrical connection: Screw Terminals
  • - Frame/Series: XT; Frame Size: B
  • - Full-load amps: Inductive 7 A; Resistive 22 A
  • - Electrical operating durability: 1000 (AC-3 400V Ie); 300 (AC-4 400V Ie); 800 (AC-1 400V Ie)
  • - Mechanical operating durability: 10000000
  • - Frequency: 50/60 Hz
  • - IP Rating: IP20
  • - Enclosure: Provided without an enclosure; suitable for installation in environments compliant with IP20 standards
  • - Dimensions: Depth 2.95 in; Height 1.77 in; Width 1.5 in
  • - Product name: Eaton XT IEC contactor
    • 🏢
