• Eaton XTCE009B01A - IEC Magnetic Contactor, 1 NC, 120 V AC, 3 P, Non-Reversing, Screw
1 1

Eaton XTCE009B01A - IEC Magnetic Contactor, 1 NC, 120 V AC, 3 P, Non-Reversing, Screw

Eaton XTCE009B01A - IEC Magnetic Contactor, 1 NC, 120 V AC, 3 P, Non-Reversing, Screw

Brand: Eaton SKU: XTCE009B01A
$101.90 USD
$101.90 USD
Sale Out of Stock - Call to Order
In Stock — Ships TODAY if ordered before 2:00 PM EST
OEM manufacturer warranty Genuine factory-sourced

Ships factory-new in original packaging.

📋 Request a Commercial Quote / PO

Not sure if a compatible flange, seal kit, or accessory exists for this item? Ask our team — we're happy to help you find the right part.

Official TIPS Contract Awarded Vendor Badge

TIPS Contract Vendor

Officially awarded purchasing cooperative vendor.

✓

Why Buy From Us

Every quote personally reviewed. Direct sourcing from top manufacturers.

View full details

The EATON - IEC Magnetic Contactor is a non-reversing, full voltage contactor designed for industrial applications. It operates with a coil voltage of 120V AC and has an amperage rating of 9A. The contactor features screw terminals for electrical connection and is compatible with both DIN Rail and Panel mounting styles. With its Frame B size, the device supports different horsepower ratings based on single or three-phase application and voltage level. This product carries multiple certifications including UL Listed, CSA Certified, IEC 60947, EN 60947, and CE Marked.

Key Features:

  • - Non-Reversing action: This means that the contactor does not have the capability to reverse its direction.
  • - Auxiliary Contact Configuration: Comes with one normally closed (1NC) auxiliary contact form.
  • - Electrical Operating Durability: Rated for up to 1000 operations at AC-3 400V Ie load type, approximately 300 operations at AC-4 400V Ie load type, and around 800 operations at AC-1 400V Ie load type.
  • - Surge Suppression: Equipped with an embedded surge suppressor which may provide additional protection against power surges.
  • - Horsepower Ratings: Designed to support a range of horsepower ratings from half hp to seven-and-a-half hp based on single or three-phase application and voltage level.
  • - Temperature Range: Rated for operation within the temperature range of -13 Degrees F minimum temperature to a maximum of +122 Degrees F.
  • -Mechanical Operating Durability: Has been tested for mechanical durability with performance observed up until ten million operating cycles under standard test conditions.
    • 🏢
