Eaton XTCF080D00T - IEC Magnetic Contactor, No Auxiliary Contacts, 24 V AC, 4 P, Non-Reversing, Screw

Eaton XTCF080D00T - IEC Magnetic Contactor, No Auxiliary Contacts, 24 V AC, 4 P, Non-Reversing, Screw

Brand: Eaton SKU: XTCF080D00T
$389.12 USD
$389.12 USD
Sale Out of Stock - Call to Order
In Stock — Ships TODAY if ordered before 2:00 PM EST
OEM manufacturer warranty Genuine factory-sourced

Ships factory-new in original packaging.

📋 Request a Commercial Quote / PO

Not sure if a compatible flange, seal kit, or accessory exists for this item? Ask our team — we're happy to help you find the right part.

Official TIPS Contract Awarded Vendor Badge

TIPS Contract Vendor

Officially awarded purchasing cooperative vendor.

✓

Why Buy From Us

Every quote personally reviewed. Direct sourcing from top manufacturers.

View full details

The Eaton XT IEC contactor is an IEC magnetic contactor with four poles and a 24 V AC coil. It has no auxiliary contacts and uses screw terminals. Non-reversing in operation, it is designed for DIN rail or panel mounting and is part of the XT series (Frame D). The device has a maximum voltage rating of 690 V AC and is designed to operate within specified current ratings; it includes a surge suppression component intended to mitigate transient voltage events.

- Coil voltage: 24 V AC

  • - Action: Non-Reversing
  • - Reversing: No
  • - Poles: 4
  • - Auxiliary contacts: No Auxiliary Contacts
  • - Frame/Series: XT, Frame D
  • - Mounting style: DIN Rail, Panel
  • - Terminal connection: Screw
  • - Maximum voltage rating: 690 V AC
  • - Frequency: 50/60 Hz
  • - Full Load Amps: 80 A (resistive), 50 A (inductive)
  • - HP ratings: 15 hp (1P 230/240V), 15 hp (3P 208V), 20 hp (3P 240V), 40 hp (3P 480V), 50 hp (3P 575V/600V)
  • - IP rating: IP20
  • - Enclosure: No Enclosure
  • - Embedded Surge Suppressor: Equipped with a surge suppression component that meets applicable standards
  • - Certifications: CE Marked; CSA Certified; EN 60947; IEC 60947; RoHS; UL Listed
  • - Operating temperature: -13°F to 122°F
  • - Mechanical durability: 10,000,000 cycles
  • - Dimensions (approx.): Height 5.9 in; Width 4.6 in; Depth 2.2 in
  • - Phase: 3
  • - Item: IEC Magnetic Contactor
    • 🏢
