• Eaton XTCF200G00A - IEC Magnetic Contactor, No Auxiliary Contacts, 120 V AC, 4 P, Non-Reversing, Screw
1 1

Eaton XTCF200G00A - IEC Magnetic Contactor, No Auxiliary Contacts, 120 V AC, 4 P, Non-Reversing, Screw

Eaton XTCF200G00A - IEC Magnetic Contactor, No Auxiliary Contacts, 120 V AC, 4 P, Non-Reversing, Screw

Brand: Eaton SKU: XTCF200G00A
$1,014.78 USD
$1,014.78 USD
Sale Out of Stock - Call to Order
In Stock — Ships TODAY if ordered before 2:00 PM EST
OEM manufacturer warranty Genuine factory-sourced

Ships factory-new in original packaging.

📋 Request a Commercial Quote / PO

Not sure if a compatible flange, seal kit, or accessory exists for this item? Ask our team — we're happy to help you find the right part.

Official TIPS Contract Awarded Vendor Badge

TIPS Contract Vendor

Officially awarded purchasing cooperative vendor.

✓

Why Buy From Us

Every quote personally reviewed. Direct sourcing from top manufacturers.

View full details

The Eaton IEC Magnetic Contactor is a four-pole, non-reversing, coil-operated switch designed to control power circuits in IEC-based systems. It has no auxiliary contacts and uses screw terminals. The device is a Frame G IEC contactor (XT series) with a 120V AC coil, rated for operation within the specified voltage range up to 690V AC, and it includes a surge suppression component. The device is supplied without an enclosure.

- Action: Non-Reversing

  • - Auxiliary Contacts: No
  • - Coil Voltage: 120V AC
  • - Coil Volts: 120 V AC
  • - Contactor Style: IEC
  • - Frame Size: G
  • - Phase: Three
  • - Frequency: 50/60 Hz
  • - Maximum Voltage Rating: maximum voltage rating of up to 690V AC within specified limits
  • - Embedded Surge Suppressor: includes a surge suppression component rated according to specifications
  • - Enclosure: supplied without an enclosure; compatible with enclosures as per installation requirements
  • - IP Rating: conforms to IP20 ingress protection rating as defined by standards
  • - Mounting Style: designed for mounting via DIN rail or panel in accordance with installation guidelines
  • - Terminal Connection Type: Screw
  • - Standards: CE, CSA, EN/IEC 60947, RoHS, UL Listed
  • - Mechanical Durability: 10000000
  • - Operating Temperature Range: -13 °F to 122 °F
  • - Dimensions (H x W x D): Height 4.83 in, Width 4.83 in, Depth 6.3 in
  • - Mounting Hole Diameter: 0.24 in
  • - Mounting Hole Distance (Height): 6.14 in
  • - Mounting Hole Distance (Width): 2.76 in
  • - Series: XT
  • - Overall Dimensions (H x W x D): 6.69 in x 5.24 in x 6.89 in
  • - Number of Auxillary Contacts: 0
  • - Includes Auxiliary Contacts: No
    • 🏢
