Gast 86R123-101-N170X - Rocking Piston Vacuum Pump, 0.125 hp
Gast 86R123-101-N170X - Rocking Piston Vacuum Pump, 0.125 hp
Couldn't load pickup availability
Ships factory-new in original packaging.
Not sure if a compatible flange, seal kit, or accessory exists for this item? Ask our team — we're happy to help you find the right part.
TIPS Contract Vendor
Officially awarded purchasing cooperative vendor.
Why Buy From Us
Every quote personally reviewed. Direct sourcing from top manufacturers.
The Gast 86R123-101-N170X is a single-cylinder rocking piston vacuum pump. It operates on 115/230V AC single-phase power at 50 Hz, 60 Hz at a rated 1/8 hp output, in a tankless configuration. It provides a free-air delivery ranging from 0.3 CFM at 100 psi up to 1.1 CFM at 0 psi, a maximum continuous pressure of 125 psi, and a maximum vacuum of 27 in Hg. It has a maximum speed of 1,725 RPM, a full-load current of 1.4/0.8 A, and a measured sound level of 65 dBA. The operating temperature range is 41 to 104°F. Construction includes an aluminum cylinder, a capacitor-start motor, and stainless steel valves. Air connections are 1/4 in NPT inlet and outlet. Overall dimensions are 7.718 x 5 x 7.078 in (L x W x H). The manufacturer lists typical applications including aeration, beverage dispensing, nitrogen generation, and tire inflation.
