Honeywell LSA7L - Limit Switch - Heavy Duty, Rotary, DPDT, Zinc Die Cast, IP67/NEMA Rated

Honeywell LSA7L - Limit Switch - Heavy Duty, Rotary, DPDT, Zinc Die Cast, IP67/NEMA Rated

Brand: Honeywell SKU: LSA7L
$321.54 USD
$321.54 USD
Sale Out of Stock - Call to Order
In Stock — Ships TODAY if ordered before 2:00 PM EST
OEM manufacturer warranty Genuine factory-sourced

Ships factory-new in original packaging.

📋 Request a Commercial Quote / PO

Not sure if a compatible flange, seal kit, or accessory exists for this item? Ask our team — we're happy to help you find the right part.

Official TIPS Contract Awarded Vendor Badge

TIPS Contract Vendor

Officially awarded purchasing cooperative vendor.

✓

Why Buy From Us

Every quote personally reviewed. Direct sourcing from top manufacturers.

View full details

The Honeywell Heavy Duty Limit Switch from the LSA Series is a rotary-style, momentary-action switch suitable for surface mounting. It features a zinc die cast body with no lever actuator included and utilizes screw terminals for electrical connection. The unit includes 2 NC and 2 NO contacts (DPDT), rated for operation up to 10A at 600VAC or up to 10A at 250VDC. Its construction is with materials rated as corrosion-resistant, with ingress protection rated at IP65/66/67 and NEMA enclosure types 1, 3, 4, 4X, 6, 6P, 12, and 13.

Key Features:

  • - Actuator Style: Rotary head without lever; side-mounted
  • - Contact Configuration: DPDT (2NC/2NO)
  • - Electrical Ratings: Up to 10A at 600VAC / up to 10A at 250VDC
  • - Body Material: Zinc die cast; standard style
  • - Mounting: Surface mount with two diagonal holes (0.20 in diameter); spacing of approximately 60 mm x 30 mm center-to-center
  • - Movement & Travel: Operates CW/CCW; differential travel of seven degrees; pretravel fifteen degrees; overtravel sixty degrees
  • - Operating Force/Torque: Requires maximum operating force of four in-lb
  • - Temperature Range: Operates between ten degrees F and two hundred fifty degrees F
  • - Protection Ratings: IP65/IP66/IP67; NEMA types as listed above
  • - Certifications: CCC, CE, CSA, UL
🏢
