Honeywell LSF4L - Limit Switch - Heavy Duty, DPDT, Side Plunger Roller, 10 A 600 V, NEMA Rated

Honeywell LSF4L - Limit Switch - Heavy Duty, DPDT, Side Plunger Roller, 10 A 600 V, NEMA Rated

Brand: Honeywell SKU: LSF4L
$901.42 USD
$901.42 USD
Sale Out of Stock - Call to Order
In Stock — Ships TODAY if ordered before 2:00 PM EST
OEM manufacturer warranty Genuine factory-sourced

Ships factory-new in original packaging.

📋 Request a Commercial Quote / PO

Not sure if a compatible flange, seal kit, or accessory exists for this item? Ask our team — we're happy to help you find the right part.

Official TIPS Contract Awarded Vendor Badge

TIPS Contract Vendor

Officially awarded purchasing cooperative vendor.

✓

Why Buy From Us

Every quote personally reviewed. Direct sourcing from top manufacturers.

View full details

The Honeywell Heavy Duty Limit Switch is a non plug-in, momentary-action device intended for use in limit switch applications. It features a side-mounted plunger actuator with a roller and utilizes a die cast zinc body made from materials specified as corrosion resistant by the manufacturer. The switch offers double pole, double throw (DPDT) contacts with 2 normally open (NO) and 2 normally closed (NC) configurations, rated at 10A for up to 600V AC or 250V DC operation. The unit is equipped with screw terminals for electrical connection and has surface mounting capability.

Key Features:

  • - Contact Rating: 10A at 600V AC / 10A at 250V DC
  • - Contact Form: DPDT (2NO/2NC)
  • - Actuator Style: Side-mounted plunger with steel roller; actuator length of 1.74"
  • - Body Construction: Die cast zinc housing; made from materials specified as corrosion resistant by the manufacturer
  • - Enclosure Ratings: NEMA types 1, 3, 4, 4X, 6, 6P,12,13; IP65/66/67
  • - Mounting Style: Surface mount with two diagonal holes (0.20" diameter), spacing of 2.34" x 1.16"
  • - Operating Temperature Range: -12°C to +93°C (10°F to +200°F)
  • - Electrical Connection: Screw terminals via threaded entry (3/4" NPT)
  • - Mechanical Travel Specs: Pretravel—0.1", Overtravel—0.19", Differential travel—0.04"
  • - Roller Dimensions: Diameter—0.5", Width—0.19"; made of steel
🏢
