Honeywell VisionPRO 8000 Commercial Thermostat - TH8321R1001
Honeywell VisionPRO 8000 Commercial Thermostat - TH8321R1001
National Boiler Supply is a premier, authorized procurement distributor for high-efficiency commercial equipment. Every order ships factory-direct, completely insured, and backed by full manufacturer engineering warranties and technical field support.
| Technical Metric | Operational Threshold Data |
|---|---|
| Manufacturer Part Number | TH8321R1001 |
| Application Compatibility | Up to 3H/2C Heat Pump or 2H/2C Conventional Systems |
| Wireless Communication protocol | RedLINK® Technology Built-In |
| Power Requirements | 24 VAC (C-Wire Required) or Battery Powered (AA Alkaline) |
| Integrated Terminal Blocks | R, RC, RH, C, W-O/B, W2-AUX/E, Y, Y2, G, A-L/A, U1, U1 |
| Operating Temperature Spectrum | 32°F to 120°F (0°C to 48.9°C) |
| Humidity Accuracy Field | 5% to 95% RH Range Control Max |
| Physical Dimensions | 4-5/8" H x 4-15/16" W x 1-1/8" D |
Couldn't load pickup availability
The Honeywell Home VisionPRO® 8000 Commercial Touchscreen Thermostat (TH8321R1001) is the ultimate multi-stage environmental management console for high-traffic facilities and light commercial architectures. Engineered with a brilliant, high-contrast digital touchscreen interface, this heavy-duty control platform handles up to 3 Heat / 2 Cool heat pump loops or 2 Heat / 2 Cool conventional systems. Backed by Honeywell's proprietary RedLINK® wireless technology, the system enables effortless integration of remote ambient temperature sensors, outdoor monitoring modules, and wireless internet gateways without modifying wall layouts.
Advanced Building Management & Efficiency Features:
- Dual-Powered Operational Infrastructure: Operates seamlessly via standard 24VAC hardwired common-wire system input, or functions independently on AA alkaline batteries for absolute field configuration versatility.
- Smart Commercial Lockout Mechanics: Advanced keypad lockout configuration settings let mechanical staff establish multi-tiered access privileges, preventing unauthorized adjustment of set points in public hallways, clinics, or classrooms.
- Dynamic Indoor Air Quality Regulation: Built-in diagnostic control logic governs integrated humidification, dehumidification, and macro-ventilation economizers, driving strict humidity and fresh air circulation limits across occupied spaces.
Scheduling Flexibility: Features a fully custom 7-day programmable scheduler equipped with Holiday Override logic and adaptive intelligent recovery capabilities, ensuring heating and cooling loops adjust dynamically ahead of scheduled peak-occupancy shifts.
