40RC111N010012 - Reducing Coupling, 1 in x 1/2 in, FNPT, 304 Stainless Steel, Class 150

The ZORO SELECT - 40RC111N010012 is a stainless steel reducing coupling that provides female NPT connections on both ends with nominal pipe sizes of 1 inch (Side A) and 1/2 inch (Side B). Constructed from 304 Stainless Steel, suitable for use with fluids and gases within the specified material and service conditions: Class 150 rating, maximum operating pressure 300 psi, maximum steam pressure 150 psi.

Key Features:

• - Material: 304 Stainless Steel
• - Connection Type: Female NPT on both sides
• - Nominal Pipe Sizes: 1" (Side A) x 1/2" (Side B)
• - Pipe Thread Size: 14 threads-per-inch on both ends
• - Pressure Rating: Class 150, supporting up to 300 psi maximum operating pressure
• - Maximum Steam Pressure: 150 psi
• - Overall Length: 50 mm
• - Suitable for use with fluids and gases within the specified material and service conditions: 304 Stainless Steel, Class 150 rating, maximum operating pressure 300 psi, maximum steam pressure 150 psi
• - Dimensions and standards compliant per ASTM-A-351, ANSI/ASME B1.20.1, and MSS-SP-114 Class 150
• - Does not include pre-applied thread sealant or additional seals
