40SE113N014 - 1/4 in 304 Stainless Steel Street Elbow, Male NPT x Female NPT, Class 150

The ZORO SELECT - 40SE113N014 is a 1/4-inch stainless steel street elbow fitting designed to connect a pipe directly to another fitting without the need for a short nipple. Constructed from 304 stainless steel, it features a 90-degree elbow shape with one male (MNPT) end and one female (FNPT) end, both threaded per NPT standards. This fitting has a Class 150 pressure rating and is compatible with Schedule 40 piping. This fitting is rated for use with air, natural gas, non-potable water, oil, potable water, and steam within its Class 150 pressure rating and 300 psi maximum operating pressure.

Key Features:

• - Material: 304 Stainless Steel
• - Size: 1/4" nominal pipe size on both male and female ends
• - Connection Types: 1/4" MNPT (male) x 1/4" FNPT (female) threads
• - Threading: 18 threads-per-inch on both ends
• - Pressure Rating: Class 150 with max operating pressure of 300 psi, max steam pressure 150 psi
• - Shape: 90-degree street elbow allowing direct connection between pipe and fitting
• - Standards: Material conforms to ASTM A-351; threads conform to ASME B1.20.1; meets MSS-SP-114 Class 150 pressure ratings
• - Applications: Suitable for air, natural gas, non-potable water, oil, potable water, and steam service
• - Color: Silver
• - Does not include pre-applied thread sealant or additional seals
• - Low lead compliance level: Compliant
