40SE113N034 - 304 Stainless Steel 90 Elbow, 3/4 in x 3/4 in Fitting Pipe Size, Male NPT x Female NPT, Class 150

The ZORO SELECT - 40SE113N034 is a 3/4-inch stainless steel street elbow fitting made from 304 stainless steel. It features one male (MNPT) end and one female (FNPT) end, both with NPT threading, allowing direct connection between a pipe and another fitting without the need for a short nipple. Rated for Class 150 service and intended for use with Schedule 40 piping per MSS-SP-114 Class 150 standards, this elbow changes the direction of flow at a 90° angle. Designed for use in piping systems with fluids compatible with 304 stainless steel within the specified Class 150 service (maximum operating pressure 300 psi; maximum steam pressure 150 psi).

Key Features:

• - Material: 304 Stainless Steel
• - Pipe Size: 3/4 inch (both ends)
• - Connection Type: Male NPT x Female NPT
• - Thread Size: 14 threads per inch on both ends
• - Pressure Rating: Class 150; Maximum Operating Pressure: 300 psi
• - Maximum Steam Pressure: 150 psi
• - Pipe Schedule Compatibility: MSS-SP-114 Class 150 (Schedule 40 piping)
• - Color: Silver
• - Standards Compliance: ASTM A-351 (material), ASME B1.20.1 (threads), MSS-SP-114 Class 150 (pressure rating)
• - Includes no pre-applied thread sealant or sealing components
• - Lead content complies with applicable potable water standards; refer to product data sheet for exact lead limits
