Parker 21SFIN13MXN - Quick Connect Socket,Brass,1 5/16" L

The PARKER - 21SFIN13MXN is a quick connect socket made from brass, designed as the female half of a quick-connect coupling. It features a push-to-connect action with a spring-loaded release sleeve and uses ball locking to accept and lock a matching plug using ball locking to form a connection intended for fluid transfer under the specified operating conditions. This quick connect socket has a 1/4 in hose fitting size with a 1/4"-18 NPTF thread size and is intended for pneumatic, hydraulic, and general fluid transfer when used with compatible couplings, hoses, and fluids. It is compatible with industrial interchange standards including A-A-59439; ISO 6150-B; MIL-C-4109F.

Key Features:

• - Body Size: 1/8"
• - Threaded Connection Type: 1/4"-18 NPTF
• - Hose Fitting Gender: Female
• - Coupling Locking Type: Ball
• - Material: Brass with Nickel Plated finish
• - Seal Material: Nitrile
• - Maximum Flow Rate: 12 SCFM
• - Rated maximum working pressure: 250 psi at 70°F
• - Rated operating temperature range: -4°F to 212°F
• - Overall Length: 1.31 in
• - Maximum Outside Diameter: 0.75 in
• - Includes Locking Balls and Valve Spring
• - Standards: A-A-59439; ISO 6150-B; MIL-C-4109F
• - For Use With: Industrial Interchange
• - Interchange Type: Industrial
• - Includes Valve: No
