Parker 25SFAN10SXZ - Quick Connect Socket,Brass,1 5/8" L

The PARKER - 25SFAN10SXZ is a quick connect coupling female component designed for pneumatic, hydraulic, or general fluid transfer applications. It accepts and locks the matching plug with the specified ball-mechanism coupling design (includes four locking balls) to provide a sealed connection when installed with compatible components and within the specified pressure and temperature ranges. Featuring a push-to-connect mechanism with a spring-loaded release sleeve and an aerodynamic internal valve, it allows rapid connection and disconnection using the push-to-connect mechanism without tools, while reducing leakage compared to an uncoupled connection; leakage rate depends on operating conditions and compatible installation. The fitting is compatible with European High Flow interchange standards (as specified by the product’s interchange requirements) and constructed primarily from brass with a nickel-plated finish.

Key Features:

• - Body size for air coupling: 1/4"
• - Connection type: 1/8"-27 NPTF thread
• - Hose fitting size: 1/8 in, male gender
• - Coupling locking type: Ball mechanism
• - Includes valve: Yes, aerodynamic type
• - Seal material: Nitrile
• - Maximum flow rate: 110 scfm
• - Maximum working pressure: 300 psi at 70°F
• - Operating temperature range: -4°F to 212°F
• - Overall length: 1.63 in (1 5/8 in)
• - Includes four locking balls
