• Schneider Electric LC1D115GD - IEC Magnetic Contactor, 1 NC/1 NO, 125 V DC, 3 P, Non-Reversing, Screw Clamp
1 1

Schneider Electric LC1D115GD - IEC Magnetic Contactor, 1 NC/1 NO, 125 V DC, 3 P, Non-Reversing, Screw Clamp

Schneider Electric LC1D115GD - IEC Magnetic Contactor, 1 NC/1 NO, 125 V DC, 3 P, Non-Reversing, Screw Clamp

Brand: Schneider Electric SKU: LC1D115GD
$664.89 USD
$664.89 USD
Sale Out of Stock - Call to Order
In Stock — Ships TODAY if ordered before 2:00 PM EST
OEM manufacturer warranty Genuine factory-sourced

Ships factory-new in original packaging.

📋 Request a Commercial Quote / PO

Not sure if a compatible flange, seal kit, or accessory exists for this item? Ask our team — we're happy to help you find the right part.

Official TIPS Contract Awarded Vendor Badge

TIPS Contract Vendor

Officially awarded purchasing cooperative vendor.

✓

Why Buy From Us

Every quote personally reviewed. Direct sourcing from top manufacturers.

View full details

The Schneider Electric IEC Magnetic Contactor is a 3-pole, non-reversing device powered by a 125 V DC coil. It includes a 1NC/1NO auxiliary contact and uses screw clamp terminals, rated for use in IEC-standard control circuit applications. It is part of the LC1D family in the TeSys range (TeSys Deca).

Key features

  • - Coil voltage: 125 V DC
  • - Poles: 3P
  • - Auxiliary contacts: 1NC/1NO (mechanically linked 1 NO + 1 NC; mirror contact 1 NC)
  • - Fuse ratings: 250 A gG (Power Circuit, coordination type 1); 200 A gG (Power Circuit, coordination type 2); 10 A gG (Signalling Circuit)
  • - Rated making capacity: 1260 A at 440 V (Power Circuit); 140 A at AC signalling voltage; 250 A at DC signalling voltage
  • - Rated breaking capacity: up to 1100 A at 440 V (Power Circuit)
  • - IP rating: IP20 front face
  • - Protective cover: Included
  • - Mounting: Rail and Plate
  • - Dimensions: Height 158 mm; Width 120 mm; Depth 136 mm
  • - Net weight: 2.5 kg
  • - Series/Range: LC1D; TeSys
  • - Reversing: Non-Reversing
  • - Electrical connection: Screw Clamp terminals
  • - Rated operational voltage: rated for operation within specified voltage ranges of up to approximately 1000 V AC and up to approximately 300 V DC
  • - Rated insulation voltage: Power Circuit 600/1000 V (CSA/UL/IEC); Signalling Circuit 690 V (IEC)
    • 🏢
