Schneider Electric LC1D1286G7 - IEC Magnetic Contactor, 1 NC/1 NO, 120 V AC, 4 P, Non-Reversing, Screw

Schneider Electric LC1D1286G7 - IEC Magnetic Contactor, 1 NC/1 NO, 120 V AC, 4 P, Non-Reversing, Screw

Brand: Schneider Electric SKU: LC1D1286G7
$196.19 USD
$196.19 USD
Sale Out of Stock - Call to Order
In Stock — Ships TODAY if ordered before 2:00 PM EST
OEM manufacturer warranty Genuine factory-sourced

Ships factory-new in original packaging.

📋 Request a Commercial Quote / PO

Not sure if a compatible flange, seal kit, or accessory exists for this item? Ask our team — we're happy to help you find the right part.

Official TIPS Contract Awarded Vendor Badge

TIPS Contract Vendor

Officially awarded purchasing cooperative vendor.

✓

Why Buy From Us

Every quote personally reviewed. Direct sourcing from top manufacturers.

View full details

The SCHNEIDER ELECTRIC IEC Magnetic Contactor is a 4-pole, non-reversing device with 1NC/1NO auxiliary contacts rated for switching resistive load power circuits within specified parameters. It is rated for operation with a 120 V AC control voltage and uses screw terminals for control and power connections. The unit is compatible with plate or rail mounting and includes a protective cover as standard feature. It is suitable for use in circuits with insulation voltages up to 690 V, within the device's specifications, with a resistive full-load current of 25 A and an inductive current of 12 A, and designed to handle current loads up to specified ratings under normal operating conditions.

- Coil voltage: 120 V AC

  • - Poles and contacts: 4P; Pole contact composition 2 NO + 2 NC; Auxiliary contacts: 1NC/1NO (mechanically linked)
  • - Connections: Screw terminals
  • - Mounting: Plate; Rail
  • - Protective cover: Included as standard feature
  • - IP rating: IP20
  • - Utilisation categories: AC-1; AC-3; AC-3e; AC-4
  • - Rated making capacity: 250 A @ 440 V (Power Circuit); 140 A (AC Signalling); 250 A (DC Signalling)
  • - Rated insulation: Power circuit 690 V; Signalling circuit 690 V
  • - Impedance: 2.5 mΩ
  • - Impulse withstand voltage: 6 kV
  • - Mechanical durability: 15 Mcycles
  • - Operating times: Closing 12–22 ms; Opening 4–19 ms
  • - Ambient and mounting limits: Permissible ambient -40 to 60°C; derating 60–70°C; Operating altitude 0–3000 m
  • - Dimensions and weight: Height 85 mm; Width 45 mm; Depth 92 mm; Net weight 0.365 kg
  • - Series: LC1D
  • - Standards: EN 60947-4-1; EN 60947-5-1; IEC 60947-4-1; IEC 60947-5-1; UL 60947-4-1; UL 60947-5-1; CSA C22.2 No 60947-4-1; CSA C22.2 No 60947-5-1; GB/T 14048.4
  • - Fuse ratings: 10 A (Signalling Circuit); 40 A (Type 1 Power Circuit); 25 A (Type 2 Power Circuit)
  • - Additional characteristics: Reversing capability: non-reversing
    • 🏢
