Schneider Electric LC1D12F7 - IEC Magnetic Contactor, 1 NC/1 NO, 110 V AC, 3 P, Non-Reversing, Screw Clamp

Schneider Electric LC1D12F7 - IEC Magnetic Contactor, 1 NC/1 NO, 110 V AC, 3 P, Non-Reversing, Screw Clamp

Brand: Schneider Electric SKU: LC1D12F7
$154.77 USD
$154.77 USD
Sale Out of Stock - Call to Order
In Stock — Ships TODAY if ordered before 2:00 PM EST
OEM manufacturer warranty Genuine factory-sourced

Ships factory-new in original packaging.

📋 Request a Commercial Quote / PO

Not sure if a compatible flange, seal kit, or accessory exists for this item? Ask our team — we're happy to help you find the right part.

Official TIPS Contract Awarded Vendor Badge

TIPS Contract Vendor

Officially awarded purchasing cooperative vendor.

✓

Why Buy From Us

Every quote personally reviewed. Direct sourcing from top manufacturers.

View full details

The item is an IEC Magnetic Contactor (TeSys Deca) with three poles and a 110 V AC coil. It is a non-reversing device with 1 normally open and 1 normally closed auxiliary contacts (2 total), and uses screw clamp terminals for wiring. Rated for switching power circuits within the specified IEC standards. It is suitable for use with motor control and resistive loads when used according to manufacturer instructions, and is provided without an enclosure; rated IP20 for indoor use only.

Key features

  • - Coil voltage: 110 V AC
  • - Poles/Main contacts: 3 main normally open contacts
  • - Auxiliary contacts: 2 total (1NO/1NC)
  • - Reversing: Non-Reversing
  • - Electrical connection: Screw Clamp Terminals
  • - Series/Frame: TeSys Deca (IEC)
  • - Frequency: 50/60 Hz
  • - Maximum voltage rating: 690 V AC
  • - Full Load Amps: 25 A (resistive); 12 A (inductive)
  • - Enclosure: No Enclosure; IP20 (indoor use only)
  • - Weight: 0.325 kg
  • - Dimensions: Depth 3.39 in; Height 3.03 in; Width 1.77 in
  • - Mounting: DIN Rail, Plate; Mounts On: Plate, Rail
  • - Protective cover: Includes protective cover
  • - Standards: EN 60947-4-1, EN 60947-5-1, UL 508, UL Listed, CSA, CSA C22.2 No 14, and others
    • 🏢
