Schneider Electric LC1DT80AG7 - IEC Magnetic Contactor, 1 NC/1 NO, 120 V AC, 4 P, Screw Clamp

Schneider Electric LC1DT80AG7 - IEC Magnetic Contactor, 1 NC/1 NO, 120 V AC, 4 P, Screw Clamp

Brand: Schneider Electric SKU: LC1DT80AG7
$672.52 USD
$672.52 USD
Sale Out of Stock - Call to Order
In Stock — Ships TODAY if ordered before 2:00 PM EST
OEM manufacturer warranty Genuine factory-sourced

Ships factory-new in original packaging.

📋 Request a Commercial Quote / PO

Not sure if a compatible flange, seal kit, or accessory exists for this item? Ask our team — we're happy to help you find the right part.

Official TIPS Contract Awarded Vendor Badge

TIPS Contract Vendor

Officially awarded purchasing cooperative vendor.

✓

Why Buy From Us

Every quote personally reviewed. Direct sourcing from top manufacturers.

View full details

The Schneider Electric IEC Magnetic Contactor is a 4-pole, 120 V AC coil device (4P) with a 1NC/1NO auxiliary contact. It is rated for switching resistive load power circuits within specified parameters and belongs to the TeSys Deca LC1D product series. The unit mounts on plate or rail and includes protective covers and compatible power connection options as specified, with control circuit terminals in screw clamps and power circuit connections via EverLink BTR screw connectors.

Key features

  • - Coil voltage: 120 V AC
  • - Poles and contacts: 4 main NO poles; auxiliary contacts 1 NC / 1 NO (2 total)
  • - Series/range: TeSys Deca LC1D product series
  • - Utilisation category: AC-1; Overvoltage category CAT III
  • - Rated currents: rated for continuous operation up to 80 A in accordance with applicable standards under specified conditions
  • - Rated making capacity: up to the listed values under standard test conditions
  • - Short-time withstand current: capable of withstanding short-duration current surges within specified limits as tested according to standards (Power circuit up to 640 A (10 s); 900 A (1 s); signalling circuit up to 140 A (100 ms))
  • - IP rating: IP20 front face
  • - Environmental: Mercury Free, PVC Free, Toxic Heavy Metal Free, Pollution Degree 3
  • - Ambient temperature: rated for operation within ambient temperatures from -40°C up to the maximum specified temperature with appropriate derating as per specifications
  • - Protection: Includes protective covers
  • - Dimensions and weight: Height 122 mm; Width 70 mm; Depth 120 mm; Net weight 1.15 kg
  • - Connections: Control Circuit - Screw Clamp Terminals; Power Circuit - EverLink BTR Screw Connectors
  • - Heat and power: Power dissipation per pole 10.2 W (AC-1); Inrush VA 140 VA; Hold VA 13 VA
  • - Impedance and electrical ratings: Impedance 1.6 mΩ; Impulse withstand voltage 6 kV
  • - Standards: EN 60947-4-1; EN 60947-5-1; IEC 60947-4-1; IEC 60947-5-1; UL 508; CSA C22.2 No 14; others listed
  • - Additional: Includes Everlink Power Connections; Range = TeSys; Protective treatment THIEC 60068-2-30; Fire ratings UL 94 V1; Fire resistance 850°C IEC 60695-2-1
    • 🏢
