• Schneider Electric LC1G1504LSEA - IEC Magnetic Contactor, 1 NC/1 NO, 200 V-500 V AC/DC, 4 P, Spring Type
1 1

Schneider Electric LC1G1504LSEA - IEC Magnetic Contactor, 1 NC/1 NO, 200 V-500 V AC/DC, 4 P, Spring Type

Schneider Electric LC1G1504LSEA - IEC Magnetic Contactor, 1 NC/1 NO, 200 V-500 V AC/DC, 4 P, Spring Type

Brand: Schneider Electric SKU: LC1G1504LSEA
$1,496.56 USD
$1,496.56 USD
Sale Out of Stock - Call to Order
In Stock — Ships TODAY if ordered before 2:00 PM EST
OEM manufacturer warranty Genuine factory-sourced

Ships factory-new in original packaging.

📋 Request a Commercial Quote / PO

Not sure if a compatible flange, seal kit, or accessory exists for this item? Ask our team — we're happy to help you find the right part.

Official TIPS Contract Awarded Vendor Badge

TIPS Contract Vendor

Officially awarded purchasing cooperative vendor.

✓

Why Buy From Us

Every quote personally reviewed. Direct sourcing from top manufacturers.

View full details

The Schneider Electric IEC Magnetic Contactor is a four-pole, coil-operated switching device rated for operation within the specified IEC standards. It is rated for operation within the specified voltage range and compatible with spring-type terminal connections. The unit includes two auxiliary contacts configured as 1NC/1NO, is part of the TeSys Giga series, has a maximum voltage rating of 1000 V AC and an IP20 ingress protection rating. It is intended for single-phase applications within its specifications, does not include an integrated surge suppression device, and supports plate mounting as per product design; durability depends on application conditions.

- Item: IEC Magnetic Contactor (Schneider Electric)

  • - Series: TeSys Giga
  • - Poles: 4
  • - Phase: Single
  • - Coil Voltage: 200–500 V AC/DC
  • - Auxiliary Contacts: 2 total (1NC/1NO)
  • - Includes Auxiliary Contacts: Yes
  • - Terminal Connection Type: Spring Type
  • - Maximum Voltage Rating: 1000 V AC
  • - Frequency: 50/60 Hz
  • - IP Rating: IP20
  • - Integrated Surge Suppressor: No
  • - Full Load Amps - Inductive: 230 A
  • - Full Load Current - Inductive: 150 A
  • - Full Load Amps - Resistive: 275 A
  • - Full Load Current - Resistive: 275 A
  • - Maximum Operating Temperature: 140 °F
  • - Minimum Operating Temperature: -13 °F
  • - Mechanical Operating Durability: 8,000,000 cycles
  • - Mounting Style: Plate
  • - Overall Dimensions: Depth 7.6 in, Height 10.04 in, Width 5.63 in
  • - Standards: CSA C22.2 No 60947-4-1, EN/IEC 60947-4-1, EN/IEC 60947-5-1, JIS C8201-4-1, JIS C8201-5-1, UL 60947-4-1
  • - Item: IEC Magnetic Contactor
    • 🏢
