• Schneider Electric LC1G2254KUEN - IEC Magnetic Contactor, 1 NC/1 NO, 100 V-250 V AC/DC, 4 P, Spring Type
1 1

Schneider Electric LC1G2254KUEN - IEC Magnetic Contactor, 1 NC/1 NO, 100 V-250 V AC/DC, 4 P, Spring Type

Schneider Electric LC1G2254KUEN - IEC Magnetic Contactor, 1 NC/1 NO, 100 V-250 V AC/DC, 4 P, Spring Type

Brand: Schneider Electric SKU: LC1G2254KUEN
$2,207.24 USD
$2,207.24 USD
Sale Out of Stock - Call to Order
In Stock — Ships TODAY if ordered before 2:00 PM EST
OEM manufacturer warranty Genuine factory-sourced

Ships factory-new in original packaging.

📋 Request a Commercial Quote / PO

Not sure if a compatible flange, seal kit, or accessory exists for this item? Ask our team — we're happy to help you find the right part.

Official TIPS Contract Awarded Vendor Badge

TIPS Contract Vendor

Officially awarded purchasing cooperative vendor.

✓

Why Buy From Us

Every quote personally reviewed. Direct sourcing from top manufacturers.

View full details

The IEC Magnetic Contactor is a 4-pole electrical switching device designed to control power circuits in accordance with IEC standards. It features a coil rated for 100–250 V (AC/DC), uses a 1NC/1NO auxiliary contact form, and contains two auxiliary contacts. The unit has no embedded surge suppressor, is designed to operate within the specified frequency range of 50/60 Hz, and is part of the TeSys Giga series with a plate mounting style for single-phase applications. It is rated for operation within the specified voltage range of up to 1000 V AC and has a IP20 ingress protection rating as per IEC standards, with an operating temperature range from -13°F to 140°F and a mechanical cycle life rating based on manufacturer specifications.

- Item: IEC Magnetic Contactor (4-pole, 2 auxiliary contacts: 1 NC/1 NO)

  • - Coil Voltage: 100–250V AC/DC
  • - Contactor Style: IEC
  • - Embedded Surge Suppressor: No
  • - Frequency: 50/60 Hz
  • - Full Load Amps (Inductive/Resistive): 290 A / 330 A
  • - Full Load Current (Inductive/Resistive): 225 A / 330 A
  • - IP Rating: IP20
  • - Includes Auxiliary Contacts: Yes (2 total)
  • - Maximum Voltage Rating: 1000V AC
  • - Maximum Operating Temperature: 140°F
  • - Minimum Operating Temperature: -13°F
  • - Mounting Style: Plate
  • - Phase: Single
  • - Series: TeSys Giga
  • - Standards: CSA C22.2 No 60947-4-1, EN/IEC 60947-4-1, EN/IEC 60947-5-1, JIS C8201-4-1, JIS C8201-5-1, UL 60947-4-1
  • - Terminal Connection Type: Spring Type
  • - Overall Dimensions: Depth 7.6 in, Height 7.6 in, Width 5.63 in
    • 🏢
