Schneider Electric LC1G265KUEN - IEC Magnetic Contactor, 1 NC/1 NO, 100 V-250 V AC/DC, 3 P, Non-Reversing, Spring Type

Schneider Electric LC1G265KUEN - IEC Magnetic Contactor, 1 NC/1 NO, 100 V-250 V AC/DC, 3 P, Non-Reversing, Spring Type

Brand: Schneider Electric SKU: LC1G265KUEN
$1,781.05 USD
$1,781.05 USD
Sale Out of Stock - Call to Order
In Stock — Ships TODAY if ordered before 2:00 PM EST
OEM manufacturer warranty Genuine factory-sourced

Ships factory-new in original packaging.

📋 Request a Commercial Quote / PO

Not sure if a compatible flange, seal kit, or accessory exists for this item? Ask our team — we're happy to help you find the right part.

Official TIPS Contract Awarded Vendor Badge

TIPS Contract Vendor

Officially awarded purchasing cooperative vendor.

✓

Why Buy From Us

Every quote personally reviewed. Direct sourcing from top manufacturers.

View full details

The item is an IEC Magnetic Contactor with 3 poles and non-reversing operation. It uses a coil rated for operation within the specified voltage ranges to actuate the main contacts and features spring-type terminal connections. It is associated with the TeSys series and includes auxiliary contacts with standard configurations.

Key features

  • - Auxiliary contact configuration: 1NC/1NO (standard auxiliary contacts)
  • - Auxiliary contact module capacity: 4
  • - Includes auxiliary contacts: Yes
  • - Number of auxiliary contacts: 3
  • - Coil voltage range: 100V–250V AC/DC
  • - Contactor style: IEC
  • - Frequency: 50/60 Hz
  • - Phase: Three
  • - Poles: 3
  • - Reversing capability: Non-Reversing
  • - Mounting style: Surface
  • - Terminal connection type: Spring Type
  • - Maximum rated operational voltage: 250V AC/DC
  • - IP rating: IP20
  • - Maximum operating temperature: 140 Degrees F
  • - Minimum operating temperature: -13 Degrees F
  • - Mechanical operating durability: 8000000 cycles
  • - Main current ratings: Full Load Amps Inductive 265 A; Full Load Amps Resistive 340 A
  • - Horsepower (Three Phase): at 208V AC – 75 hp; at 240V AC – 100 hp; at 480V AC – 200 hp; at 600V AC – 200 hp
  • - Physical dimensions are provided for reference only; actual measurements may vary
  • - Conforms to applicable standards and certifications
  • - Series: TeSys
  • - Maximum operating voltage: 250V AC/DC
  • - NEMA enclosure rating: No Enclosure
    • 🏢
