Schneider Electric LC1K090087S7 - IEC Magnetic Contactor, 2 NC/2 NO, 500 V AC, 4 P, Quick Connect

Schneider Electric LC1K090087S7 - IEC Magnetic Contactor, 2 NC/2 NO, 500 V AC, 4 P, Quick Connect

Brand: Schneider Electric SKU: LC1K090087S7
$123.16 USD
$123.16 USD
Sale Out of Stock - Call to Order
In Stock — Ships TODAY if ordered before 2:00 PM EST
OEM manufacturer warranty Genuine factory-sourced

Ships factory-new in original packaging.

📋 Request a Commercial Quote / PO

Not sure if a compatible flange, seal kit, or accessory exists for this item? Ask our team — we're happy to help you find the right part.

Official TIPS Contract Awarded Vendor Badge

TIPS Contract Vendor

Officially awarded purchasing cooperative vendor.

✓

Why Buy From Us

Every quote personally reviewed. Direct sourcing from top manufacturers.

View full details

The IEC Magnetic Contactor is a 4-pole power switching device from the LC1K series with 2NC/2NO auxiliary contacts. It is designed for use with 500 V AC coils; suitable within the specified voltage ratings. The unit uses Quick Connect terminals and is compatible with standard mounting options (Plate, Rail). It has a compact form factor (58 mm high, 45 mm wide, 57 mm deep) and a net weight of 0.18 kg.

Key features:

  • - Type/series: IEC Magnetic Contactor, LC1K, 4 poles with 2NC/2NO auxiliary contacts
  • - Coil and voltage: Designed for use with 500 V AC coils; suitable within the specified voltage ratings; Overvoltage CAT III
  • - Connections: Electrical connection Faston Terminals; Terminal connection type Quick Connect
  • - Mounting: compatible with standard mounting options (Plate, Rail)
  • - Dimensions/weight: 58 mm H x 45 mm W x 57 mm D; 0.18 kg
  • - Electrical ratings: electrical ratings based on standardized testing conditions
  • - Protection/standards: IP2X; Fire rating UL 94 V1, NF F 16-101, NF F 16-102; Standards EN/IEC 60947-4-1, UL 60947-4-1, CE, etc.
  • - Electrical performance: Inrush 30 VA; Watts Loss 1.3 W; Hold VA 4.5 VA; Impedance 3 mΩ; withstands impulse voltages up to the specified value under test conditions
  • - Environment/mechanical: Mercury Free, Toxic Heavy Metal Free; Shock Resistance up to 10–15 G; Vibration 4 G (Closed), 2 G (Open); Mechanical Durability 10 Mcycles
  • - Other specs: Working Height 6561.68 ft
🏢
