Schneider Electric LC1K0901T7 - IEC Magnetic Contactor, 1 NC, 480 V AC, 3 P, Non-Reversing, Screw Clamp

Schneider Electric’s IEC Magnetic Contactor is a 3-pole, non-reversing electric switching device rated for operation within specified parameters. It features a 480V AC coil and screw clamp terminals, with one normally closed auxiliary contact (1NC). The unit is part of the TeSys K series and is compatible with DIN rail or plate mounting; IP20 is the specified ingress protection rating.

Key features:

• - Item: IEC Magnetic Contactor; Series: TeLis K; Reversing Capability: Non-Reversing
• - Poles: 3; Auxiliary contacts: 1NC; Includes auxiliary contacts: Yes; Auxiliary contact form: 1NC
• - Coil voltage: 480V AC; Maximum voltage rating: 480V AC; Frequency: 50/60 Hz
• - Terminal connection: Screw Clamp; Mounting style: DIN Rail, Plate
• - IP rating: IP20
• - Full Load Amps: rated for use at indicated current levels under specified conditions
• - Electrical operating durability: tested for a number of operational cycles under standard test conditions
• - Mechanical operating durability: 10,000,000 cycles
• - Insulation resistance: measured according to applicable standards
• - Standards: CSA C22.2 No 60947-4-1, EN/IEC 60947-4-1, GB/T 14048.4, JIS C8201-4-1, UL 60947-4-1
• - Dimensions: Depth 2.24 in; Height 2.28 in; Width 1.77 in
• - Embedded surge suppressor: No
