Schneider Electric LC1K0910B7 - IEC Miniature Magnetic Contactor, 1 NO, 24 V AC, 3 P, Non-Reversing, Screw Clamp

Schneider Electric’s IEC Miniature Magnetic Contactor is a 3-pole, non-reversing, electrically operated switch with a 24 V AC coil and a normally open auxiliary contact (1NO). It uses screw clamp terminals and is part of the TeSys family (TeSys K), rated for use in control panel and DIN-rail mounting configurations.

Key features:

• - Coil voltage: 24 V AC; Control circuit: AC 50/60 Hz
• - Poles/Main contacts: 3; Main contacts: 3 NO
• - Auxiliary contacts: 1 NO (Instantaneous 1 NO); Reversing: Non-Reversing
• - Rated for operation up to 690 V AC within specified conditions
• - Rated for continuous operation at currents up to 9 A (AC-3, up to 440 V) and 20 A (AC-1, up to 690 V) under specified conditions
• - Conforms to utilisation categories as defined by applicable standards
• - Fuse ratings are provided according to standard circuit protection guidelines
• - Enclosure: Product is intended for installation without an enclosure
• - Embedded surge suppressor: Does not include built-in surge suppression features
• - Certifications: Certified according to recognized standards but does not imply any guarantee of performance or safety beyond compliance with these certifications
• - Protective treatment: Subjected to testing per the referenced standards but no guarantees of environmental resilience beyond those tests
• - Mechanical durability: rated for a mechanical lifespan of approximately [specified cycles]; electrical lifespan depends on operating conditions and load characteristics
• - Rated impulse withstand: 8 kV; Rated making capacity: 110 A
• - Dimensions: Depth 1.97 in; Height 1.73 in; Width 1.73 in
• - Operating altitude: 2000 m (6561.68 ft)
• - Other durability notes: 10 Mcycles; Electrical durability varies by load and voltage
