Square D LC1K0910L7 - IEC Miniature Magnetic Contactor, 1 NO, 208 V AC, 3 P, Non-Reversing, Screw Clamp

Square D LC1K0910L7 - IEC Miniature Magnetic Contactor, 1 NO, 208 V AC, 3 P, Non-Reversing, Screw Clamp

Brand: Square D SKU: LC1K0910L7
$96.13 USD
$96.13 USD
Sale Out of Stock - Call to Order
In Stock — Ships TODAY if ordered before 2:00 PM EST
OEM manufacturer warranty Genuine factory-sourced

Ships factory-new in original packaging.

📋 Request a Commercial Quote / PO

Not sure if a compatible flange, seal kit, or accessory exists for this item? Ask our team — we're happy to help you find the right part.

Official TIPS Contract Awarded Vendor Badge

TIPS Contract Vendor

Officially awarded purchasing cooperative vendor.

✓

Why Buy From Us

Every quote personally reviewed. Direct sourcing from top manufacturers.

View full details

The IEC Miniature Magnetic Contactor is a compact, electrically actuated switch rated for operation within the specified voltage and current ranges per IEC standards. It is a three-pole, non-reversing device with three normally open main contacts and one normally open auxiliary contact, energized by a 208 V AC coil. Rated for use with motors and resistive loads within specified parameters. Compatible with DIN-rail mounting as per product specifications, with screw-clamp terminals.

- Coil voltage: 208 V AC; Control circuit: AC 50/60 Hz; Poles/Main contacts: 3P, 3 NO; Auxiliary contact: Instantaneous 1 NO

  • - Application: suitable for motor control and resistive load applications within specified fuse ratings as defined by IEC 60947/VDE 0660 standards
  • - Maximum voltage rating: rated for operation up to a maximum of 480 V AC under specified conditions
  • - Embedded surge suppressor: does not include an integrated surge suppression device; compatibility with external surge protection should be verified based on application needs
  • - Enclosure: designed for installation in enclosures compliant with applicable safety standards
  • - Mounting: DIN Rail; Terminals: Screw Clamp; Series: TeSys K
  • - Rated operational current: 9 A (AC-3 up to 440 V), 20 A (AC-1 up to 690 V)
  • - Full load amps: capable of handling full load currents as specified when operated within the recommended parameters
  • - Inrush/hold power: Inrush 30 VA; Hold-in 4.5 VA
  • - Dimensions: Width 1.73 in; Height 1.73 in; Depth 1.97 in
  • - Certifications: UL Listed; CSA; CE; UKCA; CB Scheme; CCC; EAC
    • 🏢
