Taco 009 Circulator Pump
Taco 009 Circulator Pump
National Boiler Supply is a premier, authorized procurement distributor for high-efficiency commercial equipment. Every order ships factory-direct, completely insured, and backed by full manufacturer engineering warranties and technical field support.
| Technical Metric | Operational Threshold Data |
|---|---|
| Manufacturer Part Number | 009-F5 (Cast Iron Base Housing) |
| Maximum Total Dynamic Head | 35.0 Feet of Maximum Lift Pressure Capacity |
| Maximum Volumetric Flow | Up to 10 GPM (Gallons Per Minute) fluid profile |
| Electrical Specifications | 115 Volts, 60Hz, Single Phase, 1.40 Amps, 161 Watts Motor Draw |
| Flange Interface Configuration | 2-Bolt Universal Flange Pattern (Fits standard 3/4" to 1-1/2" piping flanges) |
| Fluid Temperature & Pressure Limits | 230°F (110°C) Liquid Ceiling at 150 PSI Maximum Pressure Boundary |
Couldn't load pickup availability
The Taco 009-F5 is a heavy-duty, high-head inline hydronic circulator pump engineered specifically to overcome severe fluid resistance in closed-loop heating architectures. Designed for low-flow, high-friction systems, this pump provides the massive dynamic pressure required to push heat transfer fluids efficiently through high-altitude solar collectors, restrictive outdoor wood boiler runs, and dense liquid-to-liquid heat exchangers.
Engineered for Extreme System Resistance:
- High-Head Flow Optimization: Purpose-built for systems requiring high dynamic lift but low volumetric exchange, preventing fluid stagnation in narrow manifolds or restrictive heating loops.
- Isolated Self-Lubricated Cartridge: Features Taco's field-proven drop-in cartridge design that seals all moving parts away from the motor framework. System fluid continuously cycles through the capsule to keep the ceramic sleeve bearings flawlessly lubricated and operating quietly.
- 4-Bolt Maintenance Advantage: Maximizes uptime by allowing technicians to swap out the internal mechanical core cartridge by removing only four simple motor bolts, leaving the rugged cast-iron pump casing fully intact and connected to the system piping.
Hydronic Compatibility Notice: The standard cast iron 009-F5 framework is built exclusively for closed heating systems where oxygen ingress is carefully blocked. For domestic potable hot water circulation or uninhibited open loops, the bronze-bodied 009-BF5 framework must be installed.
