Weil McLain 383-301-006 - 383-301-006 Base Assembly for LGB Series 3 Boiler, Size D
Weil McLain 383-301-006 - 383-301-006 Base Assembly for LGB Series 3 Boiler, Size D
Couldn't load pickup availability
Ships factory-new in original packaging.
Not sure if a compatible flange, seal kit, or accessory exists for this item? Ask our team — we're happy to help you find the right part.
TIPS Contract Vendor
Officially awarded purchasing cooperative vendor.
Why Buy From Us
Every quote personally reviewed. Direct sourcing from top manufacturers.
This heavy-duty base assembly provides a solid foundation for the LGB Series 3 boiler, ensuring critical structural alignment for the heating unit. By utilizing the 383-301-006 base, technicians can maintain the precise spacing required for consistent burner operation within the LGB Series 3 system architecture.
The assembly acts as the structural interface between the boiler floor and the combustion chamber, maintaining thermal stability and protecting internal components from floor-level heat transfer. It provides the necessary clearances for airflow and gas piping access, ensuring the burner assembly remains leveled and secure during high-output heating cycles.
Key System Performance Baselines:
- Structural Alignment: Maintains factory-spec tolerances for combustion chamber stability.
- Thermal Protection: Serves as a primary barrier between the burner assembly and the floor.
- Installation Efficiency: Designed for rapid integration with existing LGB boiler chassis frames.
- Durable Construction: Engineered with high-gauge materials to support the heavy weight of the LGB boiler blocks.
⚠️ Application Profile: Specifically engineered for commercial installations using Weil-McLain LGB Series 3 boilers in hydronic heating systems, requiring precise fitment for size D units.
| Performance Parameter | Engineering Baseline Value |
|---|---|
| Manufacturer Part Number (MPN) | 383-301-006 |
| Model Designation | LGB Series 3 (Size D) |
| Manufacturer | Weil-McLain |
