Grundfos ALPHA2 - ALPHA2 15-55F SF Variable-Speed Circulator
Grundfos ALPHA2 - ALPHA2 15-55F SF Variable-Speed Circulator
Couldn't load pickup availability
Ships factory-new in original packaging.
Not sure if a compatible flange, seal kit, or accessory exists for this item? Ask our team — we're happy to help you find the right part.
TIPS Contract Vendor
Officially awarded purchasing cooperative vendor.
Why Buy From Us
Every quote personally reviewed. Direct sourcing from top manufacturers.
The Grundfos ALPHA2 15-55F SF Variable Speed Circulator Pump (Model 99163937) represents the pinnacle of high-efficiency, residential and light-commercial hydronic flow technology. Engineered with a premium stainless steel pump housing and a cutting-edge electronically commutated motor (ECM), this variable-speed circulator is fully certified for both open-loop domestic potable hot water systems and closed-loop heating applications. Featuring Grundfos's patented AUTOADAPT™ intelligence, the ALPHA2 continuously analyzes zone dynamics to automatically self-adjust its performance curve—maximizing energy savings while eliminating hydraulic noise.
Key Performance Features:
- Patented AUTOADAPT™ Energy Optimization: Automatically scales motor output up or down based on real-time zone valve fluctuations, slashing electrical consumption by up to 85% compared to standard single-speed circulators.
- Premium Stainless Steel Casing (SF): Forged from high-grade stainless steel to ensure complete corrosion resistance and compliance with stringent NSF/ANSI lead-free drinking water mandates.
- Advanced Control Matrix: Offers multiple selectable modes with a clean digital LED watt/flow display, including three constant pressure settings, three constant curve settings, and standard automatic profiling.
Application Profile: Ideal for domestic hot water recirculation networks, multi-zone radiant floor manifolds, geothermal loops, indirect seasonal heating zones, and high-efficiency institutional boiler system arrays.
| Connection Type | GF 15/26 Flange (Standard 2-Bolt Universal Layout) |
| Motor Technology | High-Efficiency Electronically Commutated Motor (ECM) |
| Maximum Head Delivery | 18.05 Feet |
| Maximum Flow Output | 10.7 GPM |
| Housing Material | Premium Grade Stainless Steel (NSF Certified Open-Loop) |
| Electrical Operating Profile | 115V, 60Hz, 1-Phase (5W Minimum / 45W Maximum Draw) |
| Environmental Certifications | ETL Listed, FCC Compliant, NSF/ANSI Certified |
Corporate Procurement & PO Processing
Formal Purchase Orders (POs) and tax-exempt ordering are accepted for commercial contractors and institutional facilities.
Apply for Trade Account & Terms →📋 Procurement & Shipping Notice
- LTL Freight Dispatch: Heavy commercial units ship directly via insured LTL carrier with delivery coordination included.
- Project Timelines & Submittals: Need guaranteed delivery dates, formal submittals, or tax-exempt processing?
👉 Request a Commercial Quote or contact our procurement team for direct freight scheduling.
