Product Overview
Constructed from 304 stainless steel; suitable for high-pressure applications within specified pressure and temperature ranges. This fitting features female FNPT threaded connections on both ends, each sized at 1/2 inch nominal pipe size with 14 threads per inch using NPT threading. It is rated for use within specified pressure and temperature parameters; actual performance may vary based on installation and operating conditions. It is pressure rated to Class 3000, with a maximum pressure capacity of 3000 psi at 100 degrees F and a maximum steam pressure of 2500 psi at 350 degrees F.
Features
- Material: 304 Stainless Steel, conforming to ASTM-A-182 standard.
- Shape: 90 Degree Elbow, providing a right-angle flow change.
- Connection Type: Female NPT (FNPT) threaded ends on both sides.
- Nominal Pipe Size: 1/2 inch on both connections.
- Threading: 14 threads per inch with ANSI/ASME B1.20.1 threading standard.
- Pressure Class: Class 3000, suitable for high-pressure use.
- Maximum Pressure: 3000 psi at 100°F.
- Maximum Steam Pressure: 2500 psi at 350°F.
Technical Specifications
| Manufacturer Part Number | 2UA57 |
|---|
OEM Part Verification: Confirm part number 2UA57 against your equipment nameplate or parts list before ordering. Our order desk can cross-check it for you.
Order Desk Support: Call 850-565-3492 for formal quotes, lead times, and volume pricing.
