National Boiler Supply is a premier, authorized procurement distributor for high-efficiency commercial equipment. Every order ships factory-direct, completely insured, and backed by full manufacturer engineering warranties and technical field support.
| Technical Metric | Operational Threshold Data |
|---|---|
| Manufacturer Part Number | 007-F5-7IF (Baseline Cast Iron Model) |
| Flange/Mounting Style | 2-Bolt Universal Flanged Connection (Standard Inline Orientation) |
| Electrical Specifications | 115 Volts, 60 Hz, Single Phase (0.71 Amps Power Draw) |
| Maximum Volumetric Flow | Up to 23.0 GPM Maximum Hydraulic Capacity |
| Maximum Head Pressure | 10.0 Feet of Water Column ($10\text{ ft Head} \approx 4.33\text{ PSI}$) |
| Max Fluid Working Pressure | 125 PSI (862 kPa) Structural Limitation |
| Fluid Temperature Spectrum | 40°F to 230°F (4°C to 110°C) Closed-Loop Operational Window |
Couldn't load pickup availability
The Taco Comfort Solutions LoadMatch® Series In-Line Circulator Pump provides single-source decentralized fluid distribution for commercial and residential hydronic networks. Specially optimized for LoadMatch® decoupled single-pipe grids, these compact, self-lubricating pumps handle localized flow requirements for dedicated fan coils, radiant arrays, and terminal heat pumps—entirely eliminating the need for balancing valves, control valves, or massive secondary piping networks.
Advanced System Performance & Operational Benefits:
- Self-Balancing Fluid Operations: Because each terminal unit relies on its own dedicated LoadMatch circulator, the system automatically delivers the exact required flow rate ($GPM$) whenever the zone calls for heating or cooling. This completely eliminates manual balancing labor and field commissioning errors.
- Integrated Flow Check (IFC®) Design: Built with an internal, spring-loaded Integral Flow Check. This prevents thermo-siphoning and ghost-flows through dark zones when the pump is turned off, ensuring strict BTU management across parallel sub-loops.
- Quiet, Maintenance-Free Cartridge Architecture: Utilizes a wet-rotor design where the pumped fluid lubricates the internal bearings. The entire moving assembly is self-contained within a replaceable stainless steel cartridge sleeve, allowing simple field servicing without breaking pipe connections.
Application Warning: Standard cast iron bodies are rated exclusively for closed-loop hydronic space heating systems. For open-loop domestic potable water configurations, specify the companion bronze or stainless steel pump variations to avoid accelerated oxygen-based body oxidation.
